60''
100L/min 27Gpm
1150Kg 2530Lbs
1524mm 60inch
36Pcs
| Quantity: | |
|---|---|
| Model | Weight | Opening Width | Number of Teeth | Required Host Machine | Operation Pressure | Oil flow | L*W*H | ||||
| Unit | Kg | Lbs | mm | Inches | Pcs | Hp | Kw | Mpa | L/min | Gpm | m |
| 36 | 320 | 705 | 914 | 36 | 21 | Aboved 25HP | 18 | 14-21 | 36-100 | 10-27 | 1.25*0.65*1.5 |
| 60 | 1150 | 2530 | 1524 | 60 | 36 | Aboved 70HP | 52 | 14-21 | 100-140 | 27-37 | 1.5*1.9*1.65 |
| 72 | 1250 | 2750 | 1680 | 72 | 44 | Aboved 80HP | 60 | 14-21 | 120-150 | 32-40 | 1.5*2.2*1.65 |
| 84 | 1380 | 3036 | 1830 | 84 | 52 | Aboved 100HP | 75 | 14-21 | 120-150 | 32-40 | 1.5*2.4*1.65 |
2022 RAY Skid Steer Attachments Catalogue.pdf
SKID STEER MULCHER COSTS & OPTIONS. Disc mulcher skid steer attachments are less expensive. RAY mulchers fall into a $4000-$16000 price range and have a 36'', 48'', 60'', 72'', and 84'' cut width.
To run a mulcher, you'll need a 10-45 GPM hydraulic output, and the operating pressure caps out at 4,200 psi.
75-1.25 acres per ten hour day if operating on flat land with our smallest unit and conducting clear cutting operations.
Mulching can be a profitable service for forestry and landscaping professionals. Here are the most common applications where skid steer mulchers are being used today: Land clearing for private and public property. Site preparation and lot clearing.
